Technical Document
Specifications
Brand
Texas InstrumentsLogic Family
LVC
Logic Function
D Type
Input Type
Single Ended
Output Signal Type
Differential
Triggering Type
Positive Edge
Polarity
Inverting, Non-Inverting
Mounting Type
Surface Mount
Package Type
TSSOP
Pin Count
14
Set/Reset
Yes
Number of Elements per Chip
2
Maximum Propagation Delay Time @ Maximum CL
6 ns @ 2.7 V
Maximum Operating Supply Voltage
3.6 V
Dimensions
5 x 4.4 x 1.15mm
Propagation Delay Test Condition
50pF
Maximum Operating Temperature
+85 °C
Length
5mm
Width
4.4mm
Minimum Operating Supply Voltage
1.65 V
Minimum Operating Temperature
-40 °C
Height
1.15mm
Product details
74LVC Family Flip-Flops & Latches, Texas Instruments
Texas Instruments range of Flip-Flops and Latches from the 74LVC Family of Low-voltage CMOS Logic ICs. The 74LVC Family use silicon gate CMOS technology and is designed to operate at 3.3V, allowing a significant reduction in power consumption when compared to 5V systems.
Operating Voltage: 1.65 to 3.6V
5V tolerant inputs
Compatibility: Input LVTTL/TTL, Output LVCMOS
Latch-up performance exceeds 250 mA per JESD 17
ESD protection exceeds JESD 22
74LVC Family
Stock information temporarily unavailable.
Please check again later.
AED 1.60
Each (In a Pack of 20) (ex VAT)
AED 1.68
Each (In a Pack of 20) (inc VAT)
20
AED 1.60
Each (In a Pack of 20) (ex VAT)
AED 1.68
Each (In a Pack of 20) (inc VAT)
20
Buy in bulk
quantity | Unit price | Per Pack |
---|---|---|
20 - 20 | AED 1.60 | AED 32.00 |
40 - 80 | AED 1.15 | AED 23.00 |
100 - 180 | AED 0.80 | AED 16.00 |
200 - 380 | AED 0.75 | AED 15.00 |
400+ | AED 0.75 | AED 15.00 |
