RS PRO Digital Energy Meter, Type Energy Meter
RS Stock No. 178-5373
Brand RS Pro
- Category: Energy Meters
- Display Type: Digital
AED 164.03
in stock now
RS PRO Digital Energy Meter, Type Digital
RS Stock No. 178-5370
Brand RS Pro
- Category: Energy Meters
- Display Type: Digital
AED 158.98
in stock now
RS PRO 3 Phase Digital Energy Meter, Type Digital
RS Stock No. 179-7572
Brand RS Pro
- Cutout Height: 90mm
- Digit Height: 10 mm
- Meter Accuracy: Class 1.0
AED 481.59
in stock now
RS PRO 3 Phase LED Energy Meter, Type Digital
RS Stock No. 179-7577
Brand RS Pro
- Category: Energy Meters
- Digit Height: 10 mm
- Measurement Range: 50 mA - 6A
AED 1.952.19
in stock now
RS PRO 3 Phase LED Energy Meter, Type Digital Calibrated
RS Stock No. 179-7579
Brand RS Pro
- Depth: 55mm
- Digit Height: 10 mm
- Minimum Temperature: -10°C
AED 2.206.16
in stock now
RS PRO 3 Phase LED Energy Meter, Type Digital
RS Stock No. 179-7578
Brand RS Pro
- Depth: 55mm
- Measurement Range: 50 mA - 6A
- Meter Type: Digital
AED 641.24
in stock now
RS PRO Alpha 2 LED Digital Panel Multifunction Meter for Frequency, AC Voltage, Energy, Power, AC Current, Active, 92
RS Stock No. 136-5383
Brand RS Pro
- Minimum Temperature: -20°C
- Number Of Digits: 4
- Properties Measured: AC Current, AC Voltage, Active, Apparent Power, Frequency, Import Export Energy, Reactive
AED 528.55
in stock now
RS PRO Alpha 2 LED Digital Panel Multifunction Meter for Active, AC Current, Frequency, Power, AC Voltage, Energy, 92
RS Stock No. 136-5384
Brand RS Pro
- Category: Multi Function Panel Meters
- Measurement Range: 0.5 (Lag Power Factor), 0.5 (Lead Power Factor), 1 (Normal Power Factor), 1 → 5 (Current) A, 290 (Phase → Neutral) V ac, 45 → 65 (Frequency) Hz, 500 (Line → Line) V ac
- Meter Type: Digital
AED 573.88
in stock now
RS PRO 3 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9296
Brand RS Pro
- Number Of Digits: 7
- Number of Phases: 3
- Pulse Output: Yes
AED 785.66
in stock now
RS PRO 1 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9298
Brand RS Pro
- Category: Energy Meters
- Display Type: Backlit LCD
- Series: AP25
AED 368.28
in stock now
RS PRO 1 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9293
Brand RS Pro
- Display Type: LCD Backlit
- Number Of Digits: 7
- Number of Phases: 1
AED 400.98
in stock now
RS PRO 3 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9295
Brand RS Pro
- Category: Energy Meters
- Meter Type: Energy Meter
- Number Of Digits: 8
AED 1.055.70
in stock now
RS PRO 3 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9299
Brand RS Pro
- Cutout Height: 92mm
- Cutout Width: 92mm
- Meter Type: Energy Meter
AED 1.186.64
in stock now
RS PRO 3 Phase LCD Backlight Energy Meter, Type Energy Meter
RS Stock No. 236-9297
Brand RS Pro
- Meter Type: Energy Meter
- Number of Phases: 3
- Series: AP25
AED 1.072.10
in stock now
RS PRO 1 Phase LCD Energy Meter, Type Power
RS Stock No. 055-7782
Brand RS Pro
- Category: Energy Meters
- Category Link: https://ae.rsdelivers.com/browse/electrical-automation-cables/automation-control-gear/process-control/energy-meters
- Display Type: LCD
AED 256.78
in stock now
RS PRO LCD Energy Meter
RS Stock No. 178-5376
Brand RS Pro
- Category: Energy Meters
- Display Type: Digital
AED 163.86
in stock now
Socomec Digital Energy Meter, Type Energy Meter
RS Stock No. 221-0398
Brand Socomec
- Category Link: https://ae.rsdelivers.com/browse/electrical-automation-cables/automation-control-gear/process-control/energy-meters
- Series: DIRIS Digiware
- Standards/Approvals: IEC, UL
AED 3.898.99
in stock now
Phoenix Contact 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 220-5796
Brand Phoenix Contact
- Category Link: https://ae.rsdelivers.com/browse/electrical-automation-cables/automation-control-gear/process-control/energy-meters
- Display Type: Digital
- Number of Inputs: 1
AED 2.287.78
in stock now
Phoenix Contact 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 220-5798
Brand Phoenix Contact
- Category: Energy Meters
- Depth: 64mm
- Digit Height: 85mm
AED 1.986.01
in stock now
Phoenix Contact 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 220-5793
Brand Phoenix Contact
- Category: Energy Meters
- Meter Type: Energy Meter
- Section: Automation & Control Gear
AED 2.350.08
in stock now
Socomec 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 221-0394
Brand Socomec
- Digit Height: 85mm
- Maximum Operating Temperature: 70°C
- Series: DIRIS O-iod
AED 1.013.45
in stock now
Socomec 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 221-0396
Brand Socomec
- Depth: 65mm
- Digit Height: 85mm
- Number of Inputs: 2
AED 1.406.73
in stock now
Phoenix Contact 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 220-5797
Brand Phoenix Contact
- Number of Outputs: 1
- Product Type: Energy Meter
- Super Section: Process Control
AED 2.408.90
in stock now
Socomec 3 Phase Digital Energy Meter, Type Energy Meter
RS Stock No. 221-0395
Brand Socomec
- Cutout Height: 90mm
- Number of Outputs: 2
- Product Type: Energy Meter
AED 1.240.74
in stock now
...
What is a digital energy meter?
- kWh metering for precise billing and tariff metering
- Voltage, current, power, energy, and power factor measurements
- Data logging and export for energy reporting and sustainability programs
- Communications options such as RS485 Modbus, Modbus TCP, M‑Bus, Ethernet, and optional Wi‑Fi
What are the main types of digital energy meters?
- Single‑phase direct‑connect meters: compact meters designed for low to moderate current (often up to 100 A) that connect directly to the circuit without external current transformers.
- Single‑phase CT or split‑core CT meters: suitable for higher currents or retrofits where direct connection is not possible.
- Three‑phase four‑wire meters: measure voltage, current, and energy for three‑phase systems with neutral, common in commercial and industrial settings.
- Three‑phase three‑wire meters: used for certain 3‑phase configurations with limited neutral connections.
- Bidirectional and tariff meters: capable of tracking export/import energy for renewable generation and dynamic tariffs.
- DIN rail mounted vs panel mounted: DIN rail meters are common in electrical cabinets; panel‑mount meters suit larger enclosures or dedicated panels.
What features should I look for when buying a digital energy meter?
- Accuracy class: common classes include 0.5s, 1.0, or higher. Higher accuracy is important for precise billing and load profiling.
- Measurement channels and ranges: number of voltage/current inputs, ability to measure active/reactive energy, and phase‑level details for 3‑phase systems.
- Power measurement: real power (kW), apparent power (kVA), reactive power (kVAr), and power factor.
- Energy measurement: total active energy (kWh), reactive energy (kVArh), and time‑based energy reporting (daily, monthly totals).
- Reporting and data logging: internal memory size, logging intervals, and export formats (CSV, XML) for energy dashboards and billing systems.
- Communications: RS485 (Modbus RTU), Modbus TCP/IP, M‑Bus, Ethernet, Wi‑Fi, or Bluetooth for integration with SCADA, BMS, or data historians.
- Display and user interface: clear LCD or LED readouts, on‑device display, and remote access for quick checks.
- Mounting and enclosure: DIN rail compatibility, IP rating (for harsh environments), and temperature range appropriate to the installation.
- Safety and approvals: compliance with IEC standards (IEC 62053, IEC 61010), electrical safety, and grid connection requirements.
- Compatibility with tariffs and submetering: support for tariff metering, export/import energy tracking, and submetering capabilities for zones or equipment.
- Expansion and integration: ability to scale with additional meters, and easy integration into building management systems (BMS) or energy management software.
How does a digital energy meter work?
- The meter measures instantaneous voltage (V) and current (A) from one or more phases.
- By applying mathematical operations, it computes real power (P = V × I × cosφ) and reactive power (Q), then derives apparent power (S) and power factor (cosφ).
- Active energy (kWh) and reactive energy (kVArh) are accumulated by integrating power over time, with the meter maintaining daily, monthly, and total tallies.
- Direct‑connect meters sense current directly up to a specific limit, while CT (current transformer) meters use external CTs to measure higher currents without passing through the meter’s internal shunt.
- Digital meters store data in internal memory and often export readings via serial or Ethernet interfaces for energy dashboards, tariff analysis, and submetering reports.
How do I install and interpret a digital energy meter safely?
- Power down the panel and verify isolation before connecting meters, CTs, and wiring.
- Mount on an appropriate enclosure or DIN rail as specified; ensure correct phase wiring for 3‑phase meters.
- Connect current transformers correctly, observing polarity and CT ratios; avoid twisted or overlapping conductors that can affect accuracy.
- Verify voltage connections and ensure proper grounding; use surge protection where recommended.
- Configure communication ports (RS485, Modbus TCP, M‑Bus, Ethernet) and set address or IP parameters for remote monitoring.
- Perform safety checks, confirm readings against a known reference source if available, and document firmware versions and calibration status.
What industries and applications are best suited for digital energy meters?
- Residential and multi‑family buildings for submetering and tariff optimization
- Commercial offices, retail, and hospitality for demand management and energy budgeting
- Industrial facilities and manufacturing floors for power quality monitoring, process control, and energy analytics
- Data centers and server rooms for granular power monitoring, PUE improvements, and DCIM integration
- Solar, wind, and other distributed generation projects requiring export/import metering and tariff reconciliation
How should I read and interpret the data from a digital energy meter?
- Real‑time values: voltage, current, active power (kW), reactive power (kVAr), and power factor indicate current operating conditions.
- Energy totals: cumulative active energy (kWh) and reactive energy (kVArh) show consumption over time and are used for billing or tariff analysis.
- Phase and channel details: phase‑by‑phase readings in 3‑phase systems enable imbalance detection and targeted improvements.
- Tariff and time‑of‑use: examine energy use by time window or tariff class to optimize demand charges and running costs.
- Historical trends: data logging supports trend analysis, peak shaving, and capacity planning for facilities management.
What about communications, integration, and compatibility with building management systems?
- RS485 Modbus RTU/Modbus TCP for robust industrial connectivity and integration with SCADA and energy dashboards.
- M‑Bus for easy integration with legacy building systems and utility networks.
- Ethernet or Wi‑Fi for remote monitoring and cloud‑based energy analytics.
- Bluetooth or USB for local access and configuration during commissioning.
- Support for standard data formats (CSV, XML, JSON) to feed into submetering platforms, energy dashboards, and tariff calculation tools.
What is the difference between a digital energy meter and a power quality meter?
What should I consider regarding maintenance, calibration, and long‑term accuracy?
- Calibration intervals recommended by the manufacturer or regulatory bodies, especially for metering accuracy requirements.
- Replacement of worn components, verification of CT ratios, and inspection of wiring connections during service visits.
- Software updates to fix bugs, improve data security, and enhance communication features.
- Documenting serial numbers, firmware versions, and calibration certificates for audit readiness and customer support.
