Technical Documents
Specifications
Brand
Alpha WireSeries
Alpha Essentials Communication & Control
Product Type
Control Cable
Number of Cores
3
Conductor Material
Tin Copper Wire
Jacket Material
Polyvinyl Chloride
Jacket Colour
Grey
Screened/Unscreened
Unscreened
Outside Diameter
7.42mm
Cable Length
305m
Voltage
300V
Minimum Operating Temperature
-20°C
Conductor Type
Stranded
Maximum Operating Temperature
80°C
Standards/Approvals
CE, CSA, UL
Cable CSA
2.09mm²
Hazardous Area Certification
No
American Wire Gauge
14AWG
Fire Behaviour
Flammability Test: VW-1
Number of Strands
41
Core Strands
41 x 30AWG
Size of Strands
30AWG
Product Details
Our line-up of standard communication and control cables gives you maximum choice and fewer trade-offs. By offering you a comprehensive collection of insulation/jacketing materials, shielding options, and conductor counts, you can easily select the cable that meets your most demanding needs. We have cables that go beyond the ordinary to satisfy rigorous requirements of EMI performance, transmission distances, flexibility, and temperature extremes.
Stock information temporarily unavailable.
AED 11,732.28
AED 38.466 Each (ex VAT)
AED 12,318.89
AED 40.389 Each (inc. VAT)
305
AED 11,732.28
AED 38.466 Each (ex VAT)
AED 12,318.89
AED 40.389 Each (inc. VAT)
Stock information temporarily unavailable.
305
