Technical Document
Specifications
Brand
Alpha WireSeries
Alpha Essentials Communication & Control
Number of Cores
4
Cross Sectional Area
0.35 mm²
American Wire Gauge
22 AWG
Conductor Material
Tinned Copper
Sheath Material
PVC
Sheath Colour
Grey
Screen Type
Foil
Screened/Unscreened
Screened
Minimum Bend Radius
10 x Diameter
Outer Diameter
4.93mm
Length
100m
Voltage Rating
300 V
Standards Met
CE, CSA, UL
Maximum Operating Temperature
+75°C
Minimum Operating Temperature
-20°C
Insulation material
PE
Core Strands
7/0.25 mm
Drain Wire
Yes
Conductor Resistance
53.8 Ω/km
Product details
Stock information temporarily unavailable.
AED 1,038.60
AED 1,038.60 1 Reel of 100 Metres (ex VAT)
AED 1,090.53
AED 1,090.53 1 Reel of 100 Metres (inc. VAT)
1
AED 1,038.60
AED 1,038.60 1 Reel of 100 Metres (ex VAT)
AED 1,090.53
AED 1,090.53 1 Reel of 100 Metres (inc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | AED 1,038.60 |
| 5 - 9 | AED 1,022.22 |
| 10+ | AED 1,004.14 |
