ASSMANN WSW AWHW Series Right Angle Through Hole PCB Header, 40 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded

RS Stock No.: 674-1271Brand: ASSMANN WSWManufacturers Part No.: AWHW 40A-0202-T
brand-logo
View all in PCB Headers

Technical Document

Specifications

Brand

ASSMANN WSW

Series

AWHW

Pitch

2.54mm

Number Of Contacts

40

Number Of Rows

2

Body Orientation

Right Angle

Shrouded/Unshrouded

Shrouded

Connector System

Wire to Board

Mounting Type

Through Hole

Termination Method

Solder

Contact Plating

Gold

Contact Material

Copper Alloy

Current Rating

3.0A

Country of Origin

China

Product details

Header 90 Degrees PCB Mount 2.54mm Pitch

2.54mm Assmann Board to Board
