ATE Electronics 18kΩ Wire Wound Resistor 13W ±5% 10SR-18k-J
Technical Document
Specifications
Brand
ATE ElectronicsResistance
18kΩ
Power Rating
13W
Tolerance
±5%
Technology
Wire Wound
Series
10SR
Temperature Coefficient
±50ppm/°C
Maximum Operating Temperature
+350°C
Minimum Operating Temperature
-55°C
Product details
ATE Electronics SR Series Capacitor Balancing Resistors
The SR series of capacitor balancing resistors from ATE Electronics offers ±5% tolerance as standard. These resistors are available in E24 Series ohmic values. Featuring a dielectric strength of 1000 V ac, these balancing resistors can be used to minimise voltage imbalance from capacitors connected in a series. SR capacitor balancing resistors offer temperature coefficient values of ±100 to ±30 ppm from 10 Ω upwards. SR series resistors have been vibration tested to IEC 60571-1 standards. SR10 resistors have a 31.8mm centre and SR7 resistors have a 22.2mm centre. The fixing centre dimensions cover most of the screw terminal electrolytic capacitor offering.
Standards
IEC 60571-1
Capacitor Balancing Resistors
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 20.28
AED 20.28 Each (ex VAT)
AED 21.29
AED 21.29 Each (inc. VAT)
1
AED 20.28
AED 20.28 Each (ex VAT)
AED 21.29
AED 21.29 Each (inc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | AED 20.28 |
| 5 - 19 | AED 18.51 |
| 20 - 49 | AED 17.07 |
| 50 - 99 | AED 15.41 |
| 100+ | AED 14.07 |
