Technical Documents
Specifications
Brand
BinderNumber of Contacts
2
Product Type
Circular Connector
Mount Type
Panel Mount
Connector Size
M9
Current
4A
Plug/Socket
Socket
Contact Gender
Female
IP Rating
IP67
Series
712
Orientation
Straight
Voltage
125.0V
Shell Size
11.5 mm
Minimum Operating Temperature
-40°C
Termination Type
Solder
Maximum Operating Temperature
85°C
Housing Material
Metal
Standards/Approvals
No
Contact Plating
Gold
Contact Material
Bronze
Country of Origin
Germany
Product Details
The Binder 712 series 2-contacts, M9 female circular connector has socket type connection. This panel mount connector has a voltage rating of 125VAC and a current rating of up to 4A per contact. This connector is made of polyamide nylon with a gold plating bronze contacts. It has a compact and robust design with a screw used for locking for secure and reliable mating attenuation that meets the high requirements of industrial technology applications.
Panel plugs and sockets feature a keying groove for anti-rotation so it can be either mounted into the appropriate panel hole or mounted straight into a 12mm hole and fixed with the flange plate kit.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
AED 45.05
AED 45.05 Each (ex VAT)
AED 47.30
AED 47.30 Each (inc. VAT)
1
AED 45.05
AED 45.05 Each (ex VAT)
AED 47.30
AED 47.30 Each (inc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 49 | AED 45.05 |
| 50 - 99 | AED 42.32 |
| 100 - 249 | AED 39.38 |
| 250 - 499 | AED 36.81 |
| 500+ | AED 34.56 |
