Broadcom 5V dc 1024 PPR Pulse Optical Encoder with a 6 mm Hollow Shaft, Screw Mount, Wire Lead

RS Stock No.: 334-862Brand: BroadcomManufacturers Part No.: AEDR-8710-102
brand-logo
View all in Optical Rotary Encoders

Technical Document

Specifications

Brand

Broadcom

Pulses Per Revolution

1024 PPR

Encoder Reading

Incremental

Encoder Signal

2 Channel Quadrature

Supply Voltage

5V dc

Shaft Diameter

6 mm

Mounting Type

Screw Mount

Shaft Style

Hollow

Termination Style

Wire Lead
