ELT, 3 → 9V Output, 9W Output, 1.05A Output, Constant Current
Technical Document
Specifications
Brand
ELTOutput Voltage
3 → 9V
Maximum Output Power
9W
Output Current
1.05A
Input Voltage
198 → 264 V
Operation
Constant Current
Dimming Operation
Triac
AC or DC Input Voltage
AC, DC
Voltage Rating
198 → 264V
Standards Met
EN-55015-3-2, EN-61000-3-2, EN-61000-3-3, EN-61347-2-13, EN-61547, EN-62384
Country of Origin
Spain
Product details
ELT Dimmable LED Drivers DLC Series
The DLC 110 series by ELT is a range of dimmable constant current drivers for LED modules up to 10W.
Class II electrical protection
Indoor use
Equipped with terminal cover and cable clamps system
Maximum length of secondary wire: 5m
Suitable for installation on wooden surfaces
Permitted input voltage AC/DC: 198-264V, 0/50-60Hz. (DC/AC)
High power factor
Overload protection
Short circuit protection
Protection against no load operation
Allowed dimmers for DLC models: Trailing-edge and leading-edge dimming
Dimming 5% - 100%
Approvals
EN-61347-2-13
EN-62384
EN-61000-3-2
EN-61000-3-3
EN-55015-3-2
EN-61547
