EPCOS B32562 Polyester Film Capacitor, 250V dc, ±10%, 680nF, Through Hole
Technical Document
Specifications
Brand
EpcosCapacitance
680nF
Voltage
250V dc
Mounting Type
Through Hole
Tolerance
±10%
Series
B32562
Lead Pitch
15mm
Length
16.5mm
Depth
6mm
Height
7.8mm
Dimensions
16.5 x 6 x 7.8mm
Dielectric
Polyester
Terminal Type
Radial
Dissipation Factor
15 % @ 10 kHz
Lead Diameter
0.6mm
Maximum Operating Temperature
+125°C
Minimum Operating Temperature
-55°C
Product details
B32560 / B32562 Series
Stacked-film radial wire-ended metallised polyester film capacitors
These devices are uncoated so care must be taken to observe creepage and clearances to adjacent live parts
Ideal for general consumer and industrial electronics applications including lamp ballast circuits for energy saving lamps
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
AED 16.28
AED 1.628 Each (In a Pack of 10) (ex VAT)
AED 17.09
AED 1.709 Each (In a Pack of 10) (inc. VAT)
Standard
10
AED 16.28
AED 1.628 Each (In a Pack of 10) (ex VAT)
AED 17.09
AED 1.709 Each (In a Pack of 10) (inc. VAT)
Standard
10
Stock information temporarily unavailable.
Please check again later.
| Quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 40 | AED 1.628 | AED 16.28 |
| 50 - 90 | AED 1.522 | AED 15.22 |
| 100 - 240 | AED 1.102 | AED 11.02 |
| 250 - 490 | AED 1.05 | AED 10.50 |
| 500+ | AED 0.945 | AED 9.45 |
