ETA Thermal Circuit Breaker - 106-P30 Single Pole 250V Voltage Rating Panel Mount, 3A Current Rating
Technical Document
Specifications
Brand
ETACurrent Rating
3A
Number of Poles
1
Voltage Rating
250V
Width
11mm
Series
106-P30
Tripping Mechanism
Thermal
Reset Actuator Type
Button
Rated AC Voltage
250V
Mounting Style
Panel Mount
Circuit Breaker Type
Thermal Circuit Breaker
Overall Dimensions
19 x 11 x 8.8mm
Mounting Hole Size
9.6 x 8.9mm
Overall Depth
8.8mm
Terminal Contact Type
Blade
Overall Length
19mm
Rated DC Voltage
48V
Country of Origin
Tunisia
Product details
106-P30 Series
PCB, single hole mounting
Sub-miniature, double insulated
Trip free mechanism
Slow response time (typically 30 seconds at twice nominal current rating) ideal for inductive/reactive loads
Typical life 5000 operations (0.5 to 3A)/1000 operations (4 and 5A) at twice nominal current rating
Mainly for motors, transformers and power supplies
IEC Classification R/TO
Approvals
UL; CSA; VDE; SEV and NEMKO
