Hirose Circular Connector, 6 Contacts, Panel Mount, Miniature Connector, Male, IP67, IP68, HR30 Series
Technical Document
Specifications
Brand
HiroseNumber Of Contacts
6
Mounting Type
Panel Mount
Connector Size
Miniature
Contact Gender
Male
Termination Method
Solder
IP Rating
IP67, IP68
Current Rating
2.0A
Body Orientation
Straight
Series
HR30
Voltage Rating
100.0 V ac
Contact Plating
Gold
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
+85°C
Contact Material
Brass, Phosphor Bronze
Product details
Miniature Waterproof Plastic Connectors
The Hirose HR30 lightweight waterproof connectors have an IP67 rating which offers, when mated, a complete protection against water penetration when submerged in 1 metre of water for 30 minutes. All variations are manufactured with glass reinforced thermoplastic compounds and non corrosive components. Connectors with solder termination have solder pot inner diameters as follows:- 3 way (1.1 mm), 6-way (0.8 mm), 12-way (0.6 mm).
Push pull lock mechanism
Small and lightweight
Polarised to protect the contacts from misalignment
Built in cable strain relief
1000 mating/release cycles
Hirose Miniature Waterproof Plastic Connectors - HR30 Series
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
AED 51.50
AED 51.50 Each (ex VAT)
AED 54.08
AED 54.08 Each (inc. VAT)
1
AED 51.50
AED 51.50 Each (ex VAT)
AED 54.08
AED 54.08 Each (inc. VAT)
1
Stock information temporarily unavailable.
Please check again later.
| Quantity | Unit price |
|---|---|
| 1 - 9 | AED 51.50 |
| 10 - 49 | AED 46.67 |
| 50 - 99 | AED 42.42 |
| 100 - 249 | AED 39.06 |
| 250+ | AED 35.70 |
