Idec HE3B Series Safety Enabling Switch, 3 Position, DPDT, IP40
Technical Document
Specifications
Brand
IdecProduct Type
Safety Enabling Switch
Series
HE3B
Contact Configuration
DPDT
Number of Positions
3
IP Rating
IP40
Terminal Type
Solder
Minimum Operating Temperature
-10°C
Switch Contact Current
3 A
Maximum Operating Temperature
60°C
Contact Voltage
125V
Hazardous Area Certification
No
Standards/Approvals
IEC/EN60947-5-1, ANSI/RIA R15.06, CSA C22.2 No. 14 (c-UL), IEC60204-1/EN60204ISO11161/prEN11161, GB14048.5 (CCC Approval), UL508 (UL), IEC/EN60947-5-8 (TÜV Approval), ISO12100-1-2/EN12100-1-2, ANSI B11.19, ISO10218/EN775
Depth
2.5mm
Width
25 mm
Length
54mm
Mechanical Life
100000Operations
Country of Origin
Japan
Product details
IDEC HE3B Series Pushbutton Enabling Switch
Ideally suited for use as an enabling switch for manual robotic control, the function accomodates a panic situation wherein the operator can release or squeeze for the switch off position. The contact will not close when released from "Off" position 3 to "Off" position 1. Rubber covers are available in a choice of 3 colours, see typically Stock no 8077115.
Multiple contacts for enhanced reliability
Snap acting contacts from position 1 to 2
3 position operation Off-On-Off
Standards
IEC60947-5-1, EN60947-5-1, JIS C8201-5-1, UL508, CSA C22.2 No 14
Enabling Switch
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 207.53
AED 207.53 Each (ex VAT)
AED 217.91
AED 217.91 Each (inc. VAT)
1
AED 207.53
AED 207.53 Each (ex VAT)
AED 217.91
AED 217.91 Each (inc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | AED 207.53 |
| 5 - 9 | AED 199.66 |
| 10 - 24 | AED 192.17 |
| 25 - 49 | AED 185.27 |
| 50+ | AED 181.36 |
