ITT Cannon, Trident Female Connector Housing, 5.08mm Pitch, 24 Way, 4 Row

RS Stock No.: 466-781Brand: ITT CannonManufacturers Part No.: TST24RA00 / 192923-6040
brand-logo
View all in Wire Housings & Plugs

Technical Document

Specifications

Brand

ITT Cannon

Number Of Contacts

24

Number Of Rows

4

Pitch

5.08mm

Gender

Female

Series

Trident

For Use With

Cannon Trident Connector

Body Orientation

Straight

Length

39mm

Width

29mm

Housing Material

Nylon

Product details

Panel shells type B

ITT Canon's Trident Snap Together Connectors are a series of moulded latches and connectors for cost-effective installation. Type B panel shells directly correspond with their Type A counterparts, for a straight-forward and easy to use connection system. Trident Snap Together Connectors are available in 2 to 32 way variants.
