Jaeger With Push-Pull B00 Series Metallic Cable Gland, 3.6mm min., 6.8mm max.

RS Stock No.: 334-6315Brand: JaegerManufacturers Part No.: 7698 070 06
brand-logo
View all in Cable Glands

Technical Document

Specifications

Brand

Jaeger

Maximum Cable Diameter

6.8mm

Minimum Cable Diameter

3.6mm

Colour

Metallic

Series

With Push-Pull B00

Standards Met

RoHS Compliant

Country of Origin

France

Product details

"Miniature HD" plugs and connectors series

Features and benefits

"Miniature high density" series plugs with push-pull locking.
Available in housing size 00 with 7 contacts, or size 0 with 19 contacts.
Uses removable crimp contacts.
Nominal contact diameter: 0.76 mm (rating 22D).
Available in male or female versions.
The rear cable gland connectors are available in two versions: with a simple cable gland or with a cable gland with a 360° earth connection; these must be ordered separately.

Warning

All contacts must be installed in the insulation.

Approvals

Contact dimensions according to NFC 93422
