JST PH Series Right Angle Surface PCB Header Crimping Tool, 12 Contact(s), 2 mm Pitch, 1 Row(s), Shrouded
Technical Document
Specifications
Brand
JSTSeries
PH
Product Type
PCB Header Crimping Tool
Pitch
2mm
Current
2A
Number of Contacts
12
Housing Material
Polyamide
Number of Rows
1
Orientation
Right Angle
Shrouded/Unshrouded
Shrouded
Connector System
Wire-to-Board
Mount Type
Surface
Contact Material
Copper Alloy
Contact Plating
Gold
Minimum Operating Temperature
-25°C
Row Pitch
2mm
Termination Type
Crimp
Contact Gender
Male
Maximum Operating Temperature
85°C
Mating Pin Length
3.3mm
Standards/Approvals
No
Voltage
100 V
Country of Origin
Japan
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 23.89
AED 4.778 Each (In a Pack of 5) (ex VAT)
AED 25.08
AED 5.017 Each (In a Pack of 5) (inc. VAT)
5
AED 23.89
AED 4.778 Each (In a Pack of 5) (ex VAT)
AED 25.08
AED 5.017 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
5
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 20 | AED 4.778 | AED 23.89 |
| 25 - 45 | AED 4.305 | AED 21.52 |
| 50 - 120 | AED 3.938 | AED 19.69 |
| 125 - 245 | AED 3.675 | AED 18.38 |
| 250+ | AED 3.465 | AED 17.32 |
