Lascar DPM950 Series Digital Voltmeter DC, LCD Display 3-Digits ±1 %, 40 mm, 72 mm

RS Stock No.: 203-978Brand: LascarManufacturers Part No.: DPM 950
brand-logo
View all in Voltmeters

Technical Document

Specifications

Brand

Lascar

Product Type

Digital Voltmeter

Current Type

DC

Number of Digits

3

Display Type

LCD

Cutout Height

40mm

Cutout Width

72mm

Depth

8.4mm

Digit Height

19mm

Meter Accuracy

±1 %

Minimum Operating Temperature

0°C

Maximum Operating Temperature

50°C

Standards/Approvals

LVD 93/68/EEC, BSEN61010

Series

DPM950

Country of Origin

China

Product details

19mm, 3.5 Digit Meter - Dual Rail Input, Lascar DPM 950

Auto-zero, auto-polarity
Low battery power indication
Logic selectable decimal points
LED green backlit display for low light viewing
Backlight current: 50mA
Functions as ammeter when used with a 200mV digital current shunt

Supplied with

IDC ribbon cable connector, mounting bezel and window

LCD 5.5 to 19mm Digit Height

All have an operating temperature range of 0 to 50°C unless specified otherwise.
