Technical Documents
Specifications
Brand
Maxim IntegratedProduct Type
Voltage Level Shifter
Logic Family
LVCMOS
Number of Elements per Chip
2
Package Type
SOT-23
Output Type
3 State
Pin Count
8
Logic Function
Voltage Level Translator
Maximum Low Level Output Current
0.02mA
Maximum High Level Output Current
-0.02mA
Translation
BiCMOS
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Width
1.75mm
Length
3mm
Height
1.3mm
Product Details
Please note that any defect or non – conformance of this product must be discovered and reported to RS within 20 days of purchase.
