Technical Documents
Specifications
Brand
MetrixMultimeter Type
Bench
Product Type
Multimeter
Resistance Resolution
10Ω
Display Type
Digital
Model Number
MX 5006
Functions Measured
AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance, Temperature
Maximum AC Current Measurement
20A ac
Maximum Resistance Measurement
60mΩ
Maximum AC Voltage Measurement
1kV ac
Maximum DC Voltage Measurement
1kV dc
Maximum DC Current Measurement
20A dc
True RMS
Yes
DC Current Accuracy
0.008 % rdg
AC Voltage Accuracy
±0.005 % rdg
DC Voltage Accuracy
0.0005 % rdg
AC Current Accuracy
0.01 %
DC Current Resolution
0.0001A dc
AC Voltage Resolution
0.001V ac
AC Current Resolution
0.0001A ac
DC Voltage Resolution
0.001 V dc
Maximum Frequency
60kHz
Power Source
Mains
Minimum Operating Temperature
0°C
Resistance Measurement Accuracy
0.4 % rdg
Maximum Operating Temperature
40°C
Height
95mm
Standards/Approvals
No
Width
295mm
Length
295mm
Weight
1.9kg
Safety Category Level
CAT III
Safety Category Voltage
1000V
Country of Origin
France
Product Details
The MX 5006 bench- TOP digital multimeter can be used for TRMS AC + DC measurements. The 6000 count double transflective backlit LCD screen with bargraph and central zero offers instantaneous display of the signal variations. To ensure good measurement stability on variable speed drives, the MX 5006 bench multimeter is equipped with a 300 Hz PWM filter.
IEC 61010, 1000 V CAT III
EU Mains power cable, 1.5 m red straight/straight cable, 1.5 m black straight/straight cable, red CAT IV 1 kV test probe, black CAT IV 1 kV test probe, operating manual on CD and start-up guide on paper.
Stock information temporarily unavailable.
AED 2,272.20
AED 2,272.20 Each (ex VAT)
AED 2,385.81
AED 2,385.81 Each (inc. VAT)
Calibration type
No Calibration
1
AED 2,272.20
AED 2,272.20 Each (ex VAT)
AED 2,385.81
AED 2,385.81 Each (inc. VAT)
Stock information temporarily unavailable.
Calibration type
No Calibration
1
