Molex Straight, Through Hole, Socket Type B 2.0 USB Connector
Technical Document
Specifications
Brand
MolexGender
Female
USB Type
B
Mounting Type
Through Hole
Termination Method
Solder
USB Version
2.0
Body Orientation
Straight
Current Rating
1.0A
Voltage Rating
30.0 V
Series
On-The-Go
Contact Material
Copper Alloy
Minimum Operating Temperature
0.0°C
Maximum Operating Temperature
+50°C
Series Number
500075
Product details
USB On-The-Go (OTG)
These Molex range of USB OTG (On-the-Go) connectors are compatible with the On-The-Go supplement (Rev. 1.0) to the USB 2.0 specification. The needs of various portable and mobile equipment are met by these Molex OTG USB connectors by operating at speeds up to 480 Mbps coupled with a compact light-weight design.
Ranging from male to female, the mini USB connector also comes in USB types A, AB B and Mini B. They feature a 5-pin pitch, this reduces the mounting space required making them very versatile.
Features and Benefits
• They are about one-eighth the size of a standard USB-B connector Excellent RFI/EMI performance.
• 5-pin design (one ID pin).
• Through-hole and SMT versions available.
• Cable assemblies available.
• Voltage Rating of 30V.
• Current Rating of 1A.
• Expected Life Cycles are 5000.
Molex USB Connectors
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
AED 27.00
Each (In a Pack of 5) (ex VAT)
AED 28.35
Each (In a Pack of 5) (inc. VAT)
Standard
5
AED 27.00
Each (In a Pack of 5) (ex VAT)
AED 28.35
Each (In a Pack of 5) (inc. VAT)
Standard
5
Buy in bulk
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 120 | AED 27.00 | AED 135.00 |
| 125 - 370 | AED 18.95 | AED 94.75 |
| 375 - 995 | AED 18.15 | AED 90.75 |
| 1000 - 1995 | AED 17.70 | AED 88.50 |
| 2000+ | AED 17.30 | AED 86.50 |
