Molex 95503 Series Female RJ22 Connector, Surface Mount Straight 4P4C -Way
Technical Document
Specifications
Brand
MolexEthernet Connector Type
RJ22 Connector
Gender
Female
Mounting Type
Surface Mount
Number Of Ways
4P4C
Orientation
Straight
Length
11.18mm
Depth
15.08mm
Series
95503
Series Number
95503
Contact Material
Brass
Contact Plating
Gold over Nickel
Product details
Molex 95503 Series Cat 3 PCB Mount Vertical Standard Profile RJ Modular Jacks
95503 series Cat 3 SMT and through hole PCB mount vertical RJ45 and RJ11 modular jacks with a standard profile (15.7 mm in height), industry standard footprint. These 95503 series cat 3 modular jacks have PCB location and retention and high reliability gold plated square contacts. The through hole PCB mounting RJ modular jacks are also SMT compatible. All models are highly reliable and excellent quality.
Approvals
UL recognised component; CSA cerfified
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
AED 35.70
AED 7.14 Each (In a Pack of 5) (ex VAT)
AED 37.48
AED 7.497 Each (In a Pack of 5) (inc. VAT)
5
AED 35.70
AED 7.14 Each (In a Pack of 5) (ex VAT)
AED 37.48
AED 7.497 Each (In a Pack of 5) (inc. VAT)
5
Stock information temporarily unavailable.
Please check again later.
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | AED 7.14 | AED 35.70 |
| 50 - 95 | AED 4.988 | AED 24.94 |
| 100 - 245 | AED 4.778 | AED 23.89 |
| 250 - 495 | AED 4.672 | AED 23.36 |
| 500+ | AED 4.568 | AED 22.84 |
