Omron E5AC Panel Mount PID Temperature Controller 2 Input, 4 Output Linear 240V ac On-Off

Name: Omron E5AC Panel Mount PID Temperature Controller 2 Input, 4 Output Linear 240V ac On-Off
Brand: Omron
SKU: 7805420
Availability: LimitedAvailability

RS Stock No.: 780-5420Brand: OmronManufacturers Part No.: E5AC-CX4A5M-000Distrelec Article No.: 302-28-696

View all in Temperature Controllers

Technical Documents

Specifications

Brand

Omron

Product Type

PID Temperature Controller

Output Type

Linear

Number of Inputs

Number of Outputs

Maximum Current

50A ac

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

55°C

Terminal Type

Screw Terminal block

Control Type

On-Off

Maximum Supply Voltage

240V ac

Controlled Phases

Digital Comms

RS485

Maximum Voltage

250V

Display Type

LCD

Length

9mm

Standards/Approvals

cULus:UL 61010-1/CSA C22.2 No.61010-1, EN61326-1, EN 61010-1 (IEC 61010-1), KC mark

Width

48mm

IP Rating

IP00, IP20, IP66

Series

E5AC

Mount Type

Panel Mount

Panel Depth

60mm

Product Details

E5AC Digital Temperature Controllers (96 x 96mm)

The Temperature Controllers Series E5AC set new global standards in the crucial areas of precision, user friendliness and control performance.
This series will save you time and effort in set-up and operation, while enabling faster and more accurate monitoring/control of your process.
The high-visibility display of the new series is also extremely easy to read and virtually eliminates any possibility for human error.

High-contrast, white LCD display visible from large distances and from any angle
Easy to set up and operate intuitively via CX-Thermo without power supply
High-speed sampling at 50 ms
Functions for diagnosis for secure operations
Useful timer and logic operation functions eliminating the need of a PLC
Tool ports are provided both on the top panel and the front panel
Short body with depth of only 60 mm

Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges
