onsemi 200 V 2 A Diode Switching 2-Pin DO-214AA ES2D
Technical Document
Specifications
Brand
onsemiProduct Type
Diode
Mount Type
Surface
Package Type
DO-214AA
Maximum Continuous Forward Current If
2A
Peak Reverse Repetitive Voltage Vrrm
200V
Diode Configuration
Single
Rectifier Type
Switching
Pin Count
2
Peak Reverse Current Ir
10μA
Maximum Forward Voltage Vf
900mV
Minimum Operating Temperature
-55°C
Peak Non-Repetitive Forward Surge Current Ifsm
50A
Peak Reverse Recovery Time trr
20ns
Maximum Operating Temperature
150°C
Width
3.95 mm
Length
4.75mm
Height
2.45mm
Standards/Approvals
No
Automotive Standard
No
Product details
Rectifier Diodes, 2A to 9A, Fairchild Semiconductor
Diodes and Rectifiers, ON Semiconductor
Whether you are working on a new design, or purchasing, ON Semiconductor provides you with industry-standard diodes and rectifiers, small signal diodes, Schottky and Zener diodes. The components offer the best available combination of quality, features, and packaging options.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 17.32
AED 1.732 Each (In a Pack of 10) (ex VAT)
AED 18.19
AED 1.819 Each (In a Pack of 10) (inc. VAT)
Standard
10
AED 17.32
AED 1.732 Each (In a Pack of 10) (ex VAT)
AED 18.19
AED 1.819 Each (In a Pack of 10) (inc. VAT)
Stock information temporarily unavailable.
Standard
10
| Quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 90 | AED 1.732 | AED 17.32 |
| 100 - 240 | AED 1.522 | AED 15.22 |
| 250 - 490 | AED 1.312 | AED 13.12 |
| 500 - 990 | AED 1.155 | AED 11.55 |
| 1000+ | AED 1.102 | AED 11.02 |
