Panasonic ECQE(F) Film Capacitor 1 μF 630 V ac 630 V dc, Through Hole
Technical Document
Specifications
Brand
PanasonicProduct Type
Film Capacitor
Mount Type
Through Hole
Series
ECQE(F)
Lead Pitch
27.5mm
Automotive Standard
AEC-Q200
Maximum Operating Temperature
105°C
Length
31mm
Height
21.9mm
Standards/Approvals
EN 60384-14, CSA E60384-14, UL 60384-14
Capacitance
1μF
Lead Diameter
0.8mm
Product details
Panasonic ECQE(F) Polyester Film Capacitors
Panasonic ECQE(F) film capacitors feature flame retardant epoxy resin coating and a metallised polyester film construction. These polyester capacitors are self-healing, non-inductive and offer excellent electrical characteristics.
Lead wire type
Powder resin coated
Large capacitance range available
Wide voltage range available
Applications
ECQE(F) capacitors are recommended for general purpose usage.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 53.23
AED 10.646 Each (In a Pack of 5) (ex VAT)
AED 55.89
AED 11.178 Each (In a Pack of 5) (inc. VAT)
Standard
5
AED 53.23
AED 10.646 Each (In a Pack of 5) (ex VAT)
AED 55.89
AED 11.178 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
Standard
5
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 20 | AED 10.646 | AED 53.23 |
| 25 - 120 | AED 8.614 | AED 43.07 |
| 125 - 245 | AED 6.58 | AED 32.90 |
| 250+ | AED 6.26 | AED 31.30 |
