Panasonic 2200μF Aluminium Electrolytic Capacitor 10V dc, Radial, Through Hole - EEUHD1A222
Technical Document
Specifications
Brand
PanasonicCapacitance
2200µF
Voltage
10V dc
Mounting Type
Radial, Through Hole
Technology
Aluminium Electrolytic
Dimensions
10 (Dia.) x 16mm
Height
16mm
Minimum Operating Temperature
-55°C
Diameter
10mm
Maximum Operating Temperature
+105°C
Lifetime
2000h
Lead Pitch
5mm
Ripple Current
760mA
Leakage Current
<=0.01 CV or 3 μA @ 2 min
Tolerance
±20%
Series
HD RADIAL
Polarised
Polar
Product details
HD Series Panasonic
Panasonic HD Series Type A electrolytic capacitors feature excellent endurance of 1000 hours to 2000 hours at +105°C (dependent on case size). These radial capacitors are a miniaturised version of the NHG-A series.
Radial lead type
High reliability
Long life
Low impedance
High ripple current
Applications
Panasonic HD Series Type A electrolytic capacitors are ideal for use in industrial instruments due to their high reliability.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 35.58
AED 7.116 Each (In a Pack of 5) (ex VAT)
AED 37.36
AED 7.472 Each (In a Pack of 5) (inc. VAT)
5
AED 35.58
AED 7.116 Each (In a Pack of 5) (ex VAT)
AED 37.36
AED 7.472 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
5
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | AED 7.116 | AED 35.58 |
| 50 - 245 | AED 4.868 | AED 24.34 |
| 250 - 495 | AED 3.745 | AED 18.72 |
| 500 - 1245 | AED 3.103 | AED 15.52 |
| 1250+ | AED 2.889 | AED 14.44 |
