Panasonic ERJT08 1kΩ, 1206 (3216M) Thick Film SMD Resistor ±5% 0.33W
Technical Document
Specifications
Brand
PanasonicResistance
1kΩ
Technology
Thick Film
Package/Case
1206 (3216M)
Tolerance
±5%
Power Rating
0.33W
Temperature Coefficient
±200ppm/°C
Automotive Standard
AEC-Q200
Series
ERJT08
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
+155°C
Country of Origin
Japan
Product details
1206 Format Anti-Pulse Resistor, ERJ T08 Series - 5%
Panasonic ERJ T08 anti-pulse thick film chip resistors are constructed from three layers of electrodes and a metal glaze thick film resistive element. The optimised trimming specifications of these chip resistors ensure high pulse characteristics.
Features and Benefits:
AEC-Q200 qualified
Anti-pulse characteristics
0.33 W high-power rating
High reliability
Both reflow and flow soldering can be used
Applications
These chip resistors are AEC-Q200 qualified and are suitable for use in automotive applications.
Standards
IEC 60115-8, JIS C 5201-8, EIAJ RC-2134B
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
AED 4.20
AED 0.84 Each (In a Pack of 5) (ex VAT)
AED 4.41
AED 0.882 Each (In a Pack of 5) (inc. VAT)
Standard
5
AED 4.20
AED 0.84 Each (In a Pack of 5) (ex VAT)
AED 4.41
AED 0.882 Each (In a Pack of 5) (inc. VAT)
Standard
5
Stock information temporarily unavailable.
Please check again later.
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | AED 0.84 | AED 4.20 |
| 50 - 95 | AED 0.84 | AED 4.20 |
| 100 - 245 | AED 0.788 | AED 3.94 |
| 250 - 495 | AED 0.788 | AED 3.94 |
| 500+ | AED 0.735 | AED 3.68 |
