Panasonic, ETQP5M, 1050 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 33 μH ±20% Wire-Wound 6.5A Idc
Technical Document
Specifications
Brand
PanasonicInductance
33 μH
Maximum dc Current
6.5A
Package/Case
1050
Length
10mm
Automotive Standard
AEC-Q200
Depth
10mm
Height
5mm
Dimensions
10 x 10 x 5mm
Shielded
Yes
Tolerance
±20%
Series
ETQP5M
Core Material
Metal Composite
Maximum Self Resonant Frequency
100kHz
Moulded
Yes
Maximum Operating Temperature
+150°C
Minimum Operating Temperature
-40°C
Inductor Construction
Wire-Wound
Country of Origin
Japan
Product details
ETQP5M Series Magnetically Shielded Wire Wound Chokes
Panasonic ECQP5M choke coils provide a high reliability solution. Featuring heat resistance up to +150°C, the use of ferrous alloy magnetic material provides excellent inductance stability. New metal composite core technology creates low buzz noise, and the integral construction enables high vibration resistance.
AEC-Q200 qualified
High reliability
High bias current
Stable
Low buzz noise
High efficiency
Low RDC of winding
Low eddy-current loss of the core
Applications
Typical applications include DC-DC converters and noise filters for drive circuitry that need high peak current and operating temperature handling capabilities. These choke coils are AEC-Q200 qualified and are suitable for automotive applications.
