Phoenix Contact MINI POWER Switch Mode DIN Rail Power Supply, 85 → 264V ac ac, dc Input, 24V dc dc Output, 3.8A
Technical Document
Specifications
Brand
Phoenix ContactSeries
MINI POWER
Type
Switch Mode
Electrical Phase
1
Number of Outputs
1
AC or DC Input Voltage
ac, dc
Input Voltage
85 → 264V ac
AC or DC Output Voltage
dc
Output Voltage
24V dc
Output Current
3.8A
Dimensions
107 x 67.5 x 99mm
Height
99mm
Depth
107mm
Width
67.5mm
Maximum Temperature
+70°C
Model
MINI-PS-100-240AC/24DC/C2LPS
Efficiency
>88%
Mounting Type
DIN Rail Mount
MTBF
>815000h
Ripple And Noise
40mV Pk-Pk
Output Voltage Adjustment Range
22.5 → 26V
Minimum Temperature
-25°C
Country of Origin
Germany
Product details
Phoenix Contact MINI PS
The single phase, switch mode, Mini power supply units from Phoenix Contact have service friendly connection technology due to coded COMBICON plug connectors.
Features and Benefits
• Flexible due to the switching output voltage
• Easy maintenance connection technology
• Remote monitoring of output voltage
• IP20 protection
• Temperature range of -25°C to 70°C
• DIN Rail mounting
• Extra narrow width starting from 22.5mm
Typical Applications
Designed for use within MCR technology in measurement and control technology, urban infrastructure and building automation.
