Technical Documents
Specifications
Brand
Power IntegrationsPower Switch Topology
Flyback Converter
Power Switch Type
Off Liner
Product Type
Power Switch IC
Number of Outputs
5
Power Rating
6.1W
Number of Inputs
1
Mount Type
Through Hole
Package Type
DIP
Pin Count
7
Maximum Supply Voltage
700V
Operating Current
600μA
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
150°C
Height
3.68mm
Length
9.83mm
Standards/Approvals
RoHS, EN55022 Class B
Width
6.6mm
Series
LinkSwitch-II
Automotive Standard
No
Product Details
The LinkSwitch-II dramatically simplifies low power CV/CC charger designs by eliminating an optocoupler and secondary control circuitry. The device introduces a revolutionary control technique to provide very tight output voltage and current regulation, compensating for transformer and internal parameter tolerances along with input voltage variations.,
