RS PRO MRA440 Film Capacitor, ±10 %, 20 μF 440 V ac, Screw
Technical Document
Specifications
Brand
RS ProCapacitance
20μF
Product Type
Film Capacitor
Mount Type
Screw
Tolerance
±10 %
Series
MRA440
Automotive Standard
No
Terminal Type
Screw Mount
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
85°C
Length
98mm
Standards/Approvals
No
Dissipation Factor
0.15%
Country of Origin
United Kingdom
Product details
RS PRO Polypropylene Film Capacitor
Highly reliable Polypropylene film capacitor designed for permanent connection in the auxiliary windings of single-phase induction motors and for use with star connected three phase motors operating in a single-phase supply.
The polypropylene film element of these motor run capacitors is encapsulated in a flame-retardant resin inside self-extinguishing plastic, and all housed in an Aluminium case.
Utilising metallised film, the capacitor has excellent self-healing properties. Designed for stud mounting and particularly suited to AC, typical applications include domestic appliances.
Features and Benefits
- Nominal operating voltage of 440V
- Capacity tolerance ±10%
- Dissipation Factor ≤ 0.001
- Suitable for soldering or push-on receptacles
- Stud mount with an M8x10mm
Standards and Approvals: BS EN ISO 9001-2008, RoHS, Reach compliant
