STMicroelectronics M4T32-BR12SH1, Battery Backup IC Lithium Carbon Monofluoride, 2.8 V to 2.8 V Input, SNAPHAT 4-Pin
Technical Document
Specifications
Brand
STMicroelectronicsSub Type
Battery Backup IC
Battery Type
Lithium Carbon Monofluoride
Product Type
Battery Backup IC
Mount Type
Through Hole
Package Type
SNAPHAT
Pin Count
4
Minimum Supply Voltage
2.8V
Maximum Operating Temperature
70°C
Maximum Supply Voltage
2.8V
Minimum Operating Temperature
0°C
Standards/Approvals
No
Width
14.99 mm
Length
21.84mm
Height
6.99mm
Series
M4T32-BR12SH
Automotive Standard
No
Distrelec Product Id
301-70-607
Product details
SNAPHAT® Lithium Coin Cell Battery with Crystal, STMicroelectronics
These Battery and Crystal Option devices are detachable lithium power sources housed in special top called SNAPHAT®. The SNAPHAT is snapped on the top of the surface-mounted IC in the Printed Circuit board. Also compatible with the non-volatile TIMEKEEPER® package by STMicroelectronics.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 48.31
AED 48.31 Each (ex VAT)
AED 50.73
AED 50.73 Each (inc. VAT)
Standard
1
AED 48.31
AED 48.31 Each (ex VAT)
AED 50.73
AED 50.73 Each (inc. VAT)
Stock information temporarily unavailable.
Standard
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | AED 48.31 |
| 5 - 9 | AED 45.42 |
| 10 - 24 | AED 43.23 |
| 25 - 49 | AED 41.46 |
| 50+ | AED 40.18 |
