Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
TVS Diode
Direction Type
Uni-Directional
Diode Configuration
Single
Minimum Breakdown Voltage Vbr
14.4V
Mount Type
Surface
Package Type
SMB
Maximum Reverse Stand-off Voltage Vwm
13V
Pin Count
2
Peak Pulse Power Dissipation Pppm
600W
Maximum Peak Pulse Current Ippm
147A
ESD Protection
Yes
Clamping Voltage VC
27.2V
Minimum Operating Temperature
-55°C
Test Current It
1mA
Maximum Operating Temperature
175°C
Number of Elements per Chip
1
Length
3.95mm
Standards/Approvals
No
Width
4.6mm
Series
SMB6FxxAY
Height
1.05mm
Automotive Standard
AEC-Q101
Maximum Reverse Leakage Current
1μA
Country of Origin
Morocco
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
AED 4,012.50
AED 0.802 Each (On a Reel of 5000) (ex VAT)
AED 4,213.12
AED 0.842 Each (On a Reel of 5000) (inc. VAT)
5000
AED 4,012.50
AED 0.802 Each (On a Reel of 5000) (ex VAT)
AED 4,213.12
AED 0.842 Each (On a Reel of 5000) (inc. VAT)
Stock information temporarily unavailable.
5000
