Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Microcontroller
Series
STM32L031K6
Package Type
LQFP
Mount Type
Surface
Pin Count
32
Device Core
ARM Cortex M0+
Data Bus Width
32bit
Program Memory Size
32kB
Maximum Clock Frequency
32MHz
RAM Size
1kB
Maximum Supply Voltage
3.6V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Maximum Power Dissipation Pd
333mW
Number of Programmable I/Os
38
Height
1.45mm
Analogue Comparators
2
Length
7.2mm
Standards/Approvals
No
Width
7.2mm
Minimum Supply Voltage
1.65V
Number of Timers
1
Instruction Set Architecture
RISC
Automotive Standard
No
ADCs
10 x 12 Bit
Program Memory Type
FLASH
Country of Origin
China
Product Details
The access line ultra-low-power STM32L031x4/6 family incorporates the high-performance ARM® Cortex®-M0+ 32-bit RISC core operating at a 32 MHz frequency, high-speed embedded memories (up to 32 Kbytes of Flash program memory, 1 Kbytes of data EEPROM and 8 Kbytes of RAM) plus an extensive range of enhanced I/Os and peripherals.
The STM32L031x4/6 devices provide high power efficiency for a wide range of performance. It is achieved with a large choice of internal and external clock sources, an internal voltage adaptation and several low-power modes.
The STM32L031x4/6 devices offer several Analogue features, one 12-bit ADC with hardware oversampling, two ultra-low-power comparators, several timers, one low-power timer (LPTIM), three general-purpose 16-bit timers, one RTC and one SysTick which can be used as timebases.
Moreover, the STM32L031x4/6 devices embed standard and advanced communication interfaces: one I2C, one SPI, one USART, and a low-power UART (LPUART).
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
AED 70.62
AED 14.124 Each (In a Pack of 5) (ex VAT)
AED 74.15
AED 14.83 Each (In a Pack of 5) (inc. VAT)
Standard
5
AED 70.62
AED 14.124 Each (In a Pack of 5) (ex VAT)
AED 74.15
AED 14.83 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
Standard
5
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | AED 14.124 | AED 70.62 |
| 50 - 245 | AED 13.803 | AED 69.02 |
| 250 - 495 | AED 13.589 | AED 67.94 |
| 500+ | AED 12.894 | AED 64.47 |
