Texas Instruments 8-Channel Buffer & Line Driver, 3 State, Non-Inverting, 20-Pin TSSOP

RS Stock No.: 663-2892PBrand: Texas InstrumentsManufacturers Part No.: SN74LVC541APW
brand-logo
View all in Line Interface ICs

Technical Document

Specifications

Brand

Texas Instruments

Logic Family

LVC

Product Type

Buffer & Line Driver

Logic Function

Buffer & Line Driver

Number of Channels

8

IC Type

Buffer & Line Driver IC

Input Type

Single Ended

Output Type

3 State

Polarity

Non-Inverting

Mount Type

Surface

Package Type

TSSOP

Minimum Supply Voltage

1.65V

Pin Count

20

Maximum Supply Voltage

3.6V

Maximum High Level Output Current

-24mA

Maximum Low Level Output Current

24mA

Maximum Propagation Delay Time @ CL

5.1ns

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

125°C

Width

5.6 mm

Height

2mm

Length

7.5mm

Standards/Approvals

No

Series

SNx4LVC541A

Supply Current

10μA

Automotive Standard

AEC-Q100

Product details

74LVC Family Inverters & Buffers, Texas Instruments

Texas Instruments range of Inverters and Buffers from the 74LVC Family of Low-voltage CMOS Logic ICs. The 74LVC Family use silicon gate CMOS technology and is designed to operate at 3.3V, allowing a significant reduction in power consumption when compared to 5V systems.

Operating Voltage: 1.65 to 3.6V
5V tolerant inputs
Compatibility: Input LVTTL/TTL, Output LVCMOS
Latch-up performance exceeds 250 mA per JESD 17
ESD protection exceeds JESD 22
