TRACOPOWER TBLC Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 3.1A Output, 75W
Technical Document
Specifications
Brand
TRACOPOWERSeries
TBLC
Type
Switched Mode
Electrical Phase
1
AC or DC Input Voltage
ac
Input Voltage
85 → 264V ac
AC or DC Output Voltage
dc
Output Voltage
24V dc
Output Current
3.1A
Power Rating
75W
Number of Outputs
1
Dimensions
89.5 x 18 x 59.5mm
Depth
59.5mm
Width
59.5mm
Height
89.5mm
Minimum Temperature
-25°C
Efficiency
89%
Ripple And Noise
50mV Pk-Pk
MTBF
1900000h
Output Voltage Adjustment Range
24 → 28V
Load Regulation
0.3%
Special Features
Adjustable Output Voltage, Compliant to New Standby Power & Efficiency Requirements, Low Output Ripples & Spikes
Maximum Temperature
+70°C
Standards Met
ErP Compliant
Mounting Type
DIN Rail Mount
Country of Origin
China
Product details
TBLC Series 6 W to 90 W
The TBLC series DIN Rail mounting power supplies are designed for industrial and residential applications. They are lower cost than the existing TBL range, with similar electrical specifications. Also, they fully comply to the new standby power and efficiency requirements (ECO Standard). They are intended for connecting as Class II devices, so the safety earth connection is not required. They are mountable in flat racks due to their small dimensions in depth.
Features and Benefits
• Low profile case
• Low output ripples and spikes
• Fully compliant to ECO-Standard
• UL 1310 Class II, NEC class 2 compliance and UL 508 listed
• Universal input range 85 V ac to 264 V ac
• Operating temperature range -25°C to 70°C
• Short circuit and overload protection
• Adjustable output voltage and DC-OK indicator
Product Application Information
Suitable for industrial and residential applications.
