Technical Documents
Specifications
Brand
VishayProduct Type
Optocoupler
Mount Type
Through Hole
Maximum Forward Voltage
1.5V
Number of Channels
1
Number of Pins
6
Package Type
PDIP
Input Current Type
DC
Typical Rise Time
2μs
Maximum Input Current
60mA
Isolation Voltage
5000V ac
Logic Output
Yes
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
100°C
Maximum Current Transfer Ratio
50%
Standards/Approvals
EN 60065:2002, EN 60335, EN 60950:2000, RoHS 2002/95/EC, UL1577, WEEE 2002/96/EC
Minimum Current Transfer Ratio
20%
Typical Fall Time
2μs
Series
4N25
Automotive Standard
No
Product Details
Each optocoupler consists of gallium arsenide infrared LED and a silicon NPN phototransistor.
Stock information temporarily unavailable.
AED 101.65
AED 2.033 Each (In a Tube of 50) (ex VAT)
AED 106.73
AED 2.135 Each (In a Tube of 50) (inc. VAT)
50
AED 101.65
AED 2.033 Each (In a Tube of 50) (ex VAT)
AED 106.73
AED 2.135 Each (In a Tube of 50) (inc. VAT)
Stock information temporarily unavailable.
50
| Quantity | Unit price | Per Tube |
|---|---|---|
| 50 - 200 | AED 2.033 | AED 101.65 |
| 250 - 450 | AED 1.712 | AED 85.60 |
| 500 - 1200 | AED 1.605 | AED 80.25 |
| 1250 - 2450 | AED 1.552 | AED 77.58 |
| 2500+ | AED 1.498 | AED 74.90 |
