Vishay, IHLP-2525BD-01, 2225 (5664M) Shielded Wire-wound SMD Inductor 10 μH ±20% Wire-Wound 3A Idc
Technical Document
Specifications
Brand
VishayInductance
10 μH
Maximum dc Current
3A
Package/Case
2225 (5664M)
Length
6.86mm
Depth
6.47mm
Height
3mm
Dimensions
6.86 x 6.47 x 3mm
Shielded
Yes
Tolerance
±20%
Maximum DC Resistance
105mΩ
Series
IHLP-2525BD-01
Inductor Construction
Wire-Wound
Maximum Operating Temperature
+125°C
Minimum Operating Temperature
-55°C
