Wurth, WE-PD, 1280 Shielded Wire-wound SMD Inductor 150 μH ±20% Wire-Wound 1.8A Idc

RS Stock No.: 789-6754Brand: Wurth ElektronikManufacturers Part No.: 744770215Distrelec Article No.: 30189206
brand-logo
View all in Surface Mount Inductors

Technical Document

Specifications

Brand

Wurth Elektronik

Inductance

150 μH

Maximum dc Current

1.8A

Package/Case

1280

Length

12mm

Depth

12mm

Height

8mm

Dimensions

12 x 12 x 8mm

Shielded

Yes

Tolerance

±20%

Maximum DC Resistance

280mΩ

Series

WE-PD

Maximum Self Resonant Frequency

3MHz

Inductor Construction

Wire-Wound

Maximum Operating Temperature

+125°C

Minimum Operating Temperature

-40°C

Product details

SMD Power Inductors Type WE-PD (Metal Base 1260 - 1210)

Magnetically shielded version which results in a low leakage field
High storage capacity
Low self-losses
Highest possible current loading for SMD Inductors
Operating temperature -40 to +125°C
Recommended solder profile: Reflow
Applications: Switching regulators with low operating voltages, Integrated DC/DC-converter, Perfectly suitable for switching regulators with extremely high efficiency (>86%), Graphic cards
