Ducati Energia 4.16.10 Polypropylene Film Capacitor, 450V ac, ±5%, 80μF, Plug In
Technical Document
Specifications
Brand
Ducati EnergiaCapacitance
80µF
Voltage
450V ac
Mounting Type
Plug In
Tolerance
±5%
Series
4.16.10
Lead Length
2.8mm
Height
120mm
Dimensions
55 x 120mm
Dielectric
Polypropylene
Terminal Type
Faston
Maximum Operating Temperature
+85°C
Minimum Operating Temperature
-25°C
Dissipation Factor
<20%
Country of Origin
Italy
Product details
4.16.10/15/17/87 Series
These polypropylene film capacitors feature a self-healing metallised polypropylene dielectric. Constructed with a self-extinguishing plastic cover and case, a polyurethanic resin is used to seal the capacitive element.
Plastic case with stud
Termination via double insulated two core lead
Non-inductive winding
Low losses
Short circuits avoided due to self healing properties
Compact size
No leakage risk
Voltage for 4.16.10 Series:
400 V - 10000h cl. B - 25/85/21
425 V - 10000h cl. B - 25/85/21
450 V - 3000h cl. C 25/85/21
475 V - 3000h cl. c - 25/85/21
500 V - 1000h cl. D - SI120/20
Voltage for 4.16.15 Series:
400 V - 10000h cl. B - 25/100/21
425 V - 30000h cl. A - 25/85/21
475 V - 10000h cl. B - 25/85/21
500 V - 3000h cl. C - 25/85/21
Voltage for 4.16.87 Series:
450 V - 10000h cl. B - 25/85/21
Voltage for 4.16.17 Series:
425 V - 30000h cl. A - 25/85/21
475 V - 10000h cl. B - 25/85/21
500 V - 3000h cl. C - 25/85/21
Standards
VDE 560-8, CEI 33-3, SEV 1029
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
AED 146.20
AED 146.20 Each (ex VAT)
AED 153.51
AED 153.51 Each (inc. VAT)
1
AED 146.20
AED 146.20 Each (ex VAT)
AED 153.51
AED 153.51 Each (inc. VAT)
1
Buy in bulk
| quantity | Unit price |
|---|---|
| 1 - 4 | AED 146.20 |
| 5 - 9 | AED 142.85 |
| 10 - 24 | AED 139.35 |
| 25 - 49 | AED 130.00 |
| 50+ | AED 118.90 |
