Omron H5CX Series Panel, Panel Mount Timer Relay, 1-Contact 100V ac, 240 V ac, 0.001 s to 9999 h, 0.001 s to 9999 h,
Technical Document
Specifications
Brand
OmronProduct Type
Timer Relay
Mount Type
Panel, Panel Mount
Function
ON Delay
Time Range
0.001 s to 9999 h, 0.001 s to 9999 h
Number of Contacts
1
Number of Timer Functions
Multifunction
Contact Configuration
SPDT
IP Rating
IP66
Minimum Operating Temperature
-10°C
Contact Current
5A
Timing Adjustment
Thumbwheel Switch
Supply AC Voltage
100, 240V ac
Terminal Type
11-Pin
Maximum Operating Temperature
55°C
Height
63.7mm
Length
48mm
Standards/Approvals
CSA, EN, UR
Width
48mm
Series
H5CX
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
AED 1,271.70
AED 1,271.70 Each (ex VAT)
AED 1,335.28
AED 1,335.28 Each (inc. VAT)
1
AED 1,271.70
AED 1,271.70 Each (ex VAT)
AED 1,335.28
AED 1,335.28 Each (inc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | AED 1,271.70 |
| 5 - 9 | AED 1,220.92 |
| 10+ | AED 1,182.78 |
